Single Sided PET Tape is made from transparent/black PET film coated with a high-performance acrylate pressure-sensitive adhesive. It is resistant to bouncing, has a good shading effect, high temperature resistance, good insulation, good die-cutting properties, excellent adhesion and stress-relieving properties.
1.Insulation for membrane switch circuits, fixing and bonding.
2.Fixing and shading of LCD liquid crystal display parts and diffusion sheets inside the backlight of notebook computers, mobile phones, PDAs, etc.
3. Adhesion of graphite sheets inside mobile phones.
4.Adhesive fixing of internal parts of other consumer electronic products.
| Property | ||||||||
| Product Code Technical Parameters |
P5501 | P5503 | P5505 | P55075 | P5510 | P55125 | P5515 | P5520 |
| Color | Transparent/Black | Black | ||||||
| Total Thickness[mm] | 0.01 | 0.03 | 0.05 | 0.075 | 0.1 | 0.125 | 0.15 | 0.2 |
| PET Backing[mm] | 0.002 | 0.012 | 0.025 | 0.05 | 0.075 | 0.075 | 0.1 | 0.15 |
| Initial Adhesion（No.#） | 1 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| 180°Peel Strength[N/inch] | ≥0.8 | ≥0.8 | ≥1.2 | ≥1.2 | ≥1.5 | ≥1.5 | 1.5 | 1.8 |
| Retentivity[hour] | ≥48 | ≥48 | ≥48 | ≥48 | ≥48 | ≥48 | ≥48 | ≥48 |
| Long-Term Temperature Resistance ℃ | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
| Short-Term Temperature Resistance ℃ | 120 | 120 | 120 | 120 | 120 | 120 | 120 | 120 |
What are the characteristics of black PET tape?
1. Excellent adhesion: Coated with high-performance acrylic pressure-sensitive adhesive to ensure strong adhesion between the tape and various substrates.
2. Good shading effect: Black PET tape can effectively block light, providing an ideal solution for application scenarios that require shading.
3. High temperature resistance: It can maintain stable performance in high temperature environments and is suitable for various high temperature working environments.
4. Excellent insulation performance: Excellent insulation performance ensures circuit safety and prevents short circuits and leakage.
Excellent die-cutting performance: easy to die-cut and process, meeting the needs of various shapes and sizes.
Application of black PET tape?
Membrane switch circuit insulation: Black PET tape is used for the insulation of membrane switch circuits to protect the circuit from external interference and damage.
Fixing and shading of LCD display components: Black PET tape fixes the LCD components and diffusion sheets in backlight modules of laptops, mobile phones, PDAs, etc., while providing a shading effect.
Adhesion of graphite sheets inside the mobile phone: black PET tape adheres graphite sheets inside the mobile phone for heat dissipation and heat conduction.
Adhesion and fixation of internal components of other consumer electronic products: widely used in the fixation and adhesion of internal components of various consumer electronic products.
Specification data
